JLG 70H Parts Manual User Manual
Page 180
2-102
3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
7020421
Nozzle, Injector
1
7020422
Injector
1
7020423
Gasket, Injector Tip
1
7020433
Gasket
1
7020465
Cap, Filler (Engine F3L912 - 2000066 & 2000094)
1
7026173
Switch, Broken Belt
1
7026668
Plug
2
7016330
Switch, Oil Pressure
1
70001361
Pump, Fuel Injector (Engine F4L912 - 2000083)
4
70001928
Gasket, Exhaust Manifold (Engine F4L912 -
2000083)
4
70002252
Ring, Head Fire (Engine F4L912 - 2000083)
4
70002253
Complete Engine Gasket Set (Engine F4L912 -
2000083)
1
70002254
Piston/Cylinder Kit (Engine F4L912 - 2000083)
4
70002258
Bolt, Cylinder Head (Engine F4L912 - 2000083)
4
70002259
Washer, Head Bolt (Engine F4L912 - 2000083)
4
7020498
Fan (Engine F4L912 - 2000083)
1
7026125
Flange, Exhaust (Engine F4L912 - 2000083)
1
7027250
Spring, Tension (Actuator) (Engine F4L912 -
2000083)
1
FIGURE 2-25. DEUTZ ENGINE INSTALLATION WITH NOISE REDUCTION (BUILT DECEMBER 1992
TO PRESENT) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
