3120290 2-165
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-38. MAIN PUMP ASSEMBLY (MACHINES WITH VICKERS PROPORTIONAL VALVES
BUILT PRIOR TO MID 1987 - HAS ONE OUTLET IN END COVER)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
MAIN PUMP ASSEMBLY (MACHINES WITH VICKERS
PROPORTIONAL VALVES BUILT PRIOR TO MID 1987
- HAS ONE OUTLET IN END COVER)
Ref. C
3600072 PUMP ASSEMBLY Ref.
1 Kit Seal, Lip 1
2 7005509 Cover, End 1
3 Kit Seal, Ring 6
4 7003103 Plug 1
5 7003168 Bearing, Roller 12
6 7005511 Plate, Thrust 6
7 Kit Seal, Pocket 3 strips
8 7005505 Shaft and Gear 1 set
9 Kit Seal, Gasket 6
10 7003176 Housing, Gear 1
11 7005512 Carrier, Bearing 1
12 7003174 Shaft, Connecting 2
13 7003177 Gear Set 2 sets
14 7003178 Housing, Gear 2
15 7005513 Carrier, Bearing 1
16 7005541 Cover, Rear 1
17 7001293 Washer 4
18 7005542 Stud 4
19 7003114 Nut 4
— — — — — — — — — —
2900120 Kit, Seal (Kit Includes Items 1, 3, 7 and 9) 1
