3120290 4-5
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
126 1380137 Clip, Retainer 2
127 4751800 Flatwasher 1/2” 1
128 Cover, Rotator Options: 1
1670322 60H/70H
1670421 60H+6
129 3311805 Locknut 1/2”-13NC 1
130 Bolt Options: 1
0641612 Bolt 3/8”-16NC x 1 1/2” (60H/70H)
0641405
Bolt 1/4”-20NC x 5/8” (60H+6) (Used after Novem-
ber 1991)
131 Lockwasher 3/8” Options: 1
4761600 60H/70H
Not Required 60H+6
132 Wire, Mechanics A/R
4920986 60H/70H
4920385 60H+6
133 4761800 Lockwasher 1/2” 2
134 Pin Options: 1
Not Required 60H/70H
60H+6 Options: 1
3421426 Pin (Prior to January 1991)
3421825 Pin (January 1991 to November 1991)
3422019 Pin (November 1991 to Present)
0100011 Loctite #242 A/R
Note: Items 135 to 139 Used on 60H+6 Only
135 Retainer Options: 1
Not Required (Prior to January 1991)
4740385 Washer (January 1991 to November 1991)
0362079 Bar (November 1991 to Present)
136 3900159
Screw, Countersunk 1/2”-13NC x 3/4” (Used after
January 1991)
1
137 3760237 Ring, Retaining (Prior to January 1991) 1
138 1670422 Cover, Motor 1
139 0641406 Bolt 1/4”-20NC x 3/4” 2
0235238 ROTATOR ASSEMBLY Ref. E
Note: For Machines Built Prior to September 1991
refer to Service Information Bulletin #91-5 for
required upgrade.
201 3160083
Rotator Motor Assembly (See Figure 4-3 for
Breakdown)
1
202 0080099 Adapter, Motor 1
203 2760064 Housing, Gear 1
204 0440134 Bearing, Sleeve 2
205 4740199 Washer, Thrust 4
206 0440120 Bearing, Thrust 2
207 2440043 Gear, Worm 1
208 3440816 Rollpin 1/4” x 1” 4
209 0080098 Adapter, Motor to Worm Gear 1
FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
