JLG 70H Parts Manual User Manual
Page 170
2-92
3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
314
4100025
Sleeve, Fiberglass (Not Shown)
15.6”
315
0901387
Bracket, Hanger
2
316
0641507
Bolt 5/16”-18NC x 7/8”
2
317
4751500
Flatwasher 5/16”
2
318
4761500
Lockwasher 5/16”
2
319
3311501
Nut 5/16”-18NC
2
320
0641607
Bolt 3/8”-16NC x 7/8”
1
321
4751600
Flatwasher 3/8”
1
322
4761600
Lockwasher 3/8”
1
323
3311601
Nut 3/8”-16NC
1
324
0181286
Angle, Support
1
325
2551030
Gusset
1
326
0901719
Bracket, Support
1
327
4740252
Flatwasher, Special
3
0237541
EXHAUST INSTALLATION - MACHINES BUILT
APRIL 1986 TO JANUARY 1989 (SEE SECTION 10
FOR NON-STANDARD EXHAUST SYSTEMS)
Ref.
-
341
3220043
Muffler
1
342
1320019
Clamp, Exhaust
1
343
1320062
Clamp, Exhaust
1
344
4562929
Pipe, Exhaust
1
345
4340483
Support
1
346
4740252
Flatwasher, Special
3
0252050
EXHAUST INSTALLATION - MACHINES BUILT
DECEMBER 1991 TO DECEMBER 1992 (SEE
SECTION 10 FOR NON-STANDARD EXHAUST
SYSTEMS)
Ref.
A
351
3220080
Muffler
1
352
0340041
Band, Muffler
2
353
0641406
Bolt 1/4”-20NC x 3/4”
4
354
4751400
Flatwasher 1/4”
4
355
4761400
Lockwasher 1/4”
4
356
3311401
Nut 1/4”-20NC
4
357
1320011
Clamp
4
358
1120406
Rain-Cap
1
359
4565267
Tube, Exhaust
2
360
4565268
Tube, Flex Exhaust
1
361
4565269
Adaptor, Exhaust
1
0236389
BATTERY INSTALLATION
Ref.
B
401
0400020
Battery
1
402
3509770
Tray, Battery
1
403
0361027
Bar
1
404
1060147
Cable, Battery (+ Batt to Starter)
1
FIGURE 2-24. DEUTZ ENGINE INSTALLATION WITHOUT NOISE REDUCTION (BUILT PRIOR TO
DECEMBER 1992) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
