JLG 70H Parts Manual User Manual
Page 209
3120290
2-131
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-31. GENERATOR INSTALLATION - FORD ENGINE MACHINES BUILT PRIOR TO
FEBRUARY 1995
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GENERATOR INSTALLATION - FORD ENGINE
MACHINES BUILT PRIOR TO FEBRUARY 1995
(OPTIONAL)
Ref.
Note: U/L Machines use special items listed in Sec-
tion 10 plus items listed below.
GENERATOR INSTALLATION (STANDARD PARTS)
Ref.
1
Not Used
2
0641508
Bolt 5/16”-18NC x 1”
3
3
4761500
Lockwasher 5/8”
4
4
V-Belt Options:
1
0480037
(Prior to May 1987)
0480048
(May 1987 to February 1995)
5
3580134
Pulley
1
6
2460011
Generator and Control Box Assembly
1
7012558
Generator Assembly
1
7020193
Power Cord
1
7026199
Armature
1
7020108
Brush
4
7020109
Holder, Brush
4
7012513
Cap, Brush Holder
4
7012514
Fan
1
7020110
Bell End, Front
1
7020111
Bell End, Rear
1
7020190
Bearing
2
7003657
Control Box Assembly
1
Note: Replacement 110V Control Box comes
with 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n
4460027 must be ordered separately.
4360542
Breaker, Circuit
1
2420203
Voltmeter
1
4460190
Receptacle
2
2920162
Lamp
1
7020191
Switch, Toggle
1
3520028
Plug, Hole
1
7020194
Breaker, Circuit
1
7
Not Used
8
4751500
Flatwasher 5/16”
1
9
Not Used
10
Not Used
11
0701021
Bolt, Metric 10mm x 65mm
2
12
Not Used
13
Not Used
14
Not Used
15
Not Used
16
0721004
Screw, Machine #10-24NC x 1/2”
2
17
4751000
Flatwasher #10
4
