JLG 70H Parts Manual - Manual (Page 381)

3120290 5-35
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
FIGURE 5-13. CYLINDER BELLOWS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CYLINDER BELLOWS INSTALLATION Ref.
1280547
CYLINDER BELLOWS INSTALLATION (PRIOR TO
MAY 1992)
Ref. D
1281861
CYLINDER BELLOWS INSTALLATION (MAY 1992
TO PRESENT)
Ref. -
1 0460070 Bellows with Zipper (Lift Cylinder) 1
2 0460071 Bellows with Zipper (Master Cylinder) 1
3 Bellows with Zipper Options (Slave Cylinder): 1
0460101 60H and 70H
0460081 60H+6 Extend-A-Reach
4 Bellows with Zipper Options (Front Steer Cylinder): 1
0460073 2WD
0460075 4WD
5 0460075 Bellows with Zipper (Rear Steer Cylinder) 1
6
Bellows with Zipper Options (Axle Lockout Cylin-
ders):
2
0460074 Machines Built Prior to May 1992
0460104 Machines Built May 1992 to Present
7 1320122 Clamp, Worm Gear 5 1/8”-6” Dia. A/R
8 1320037 Clamp, Worm Gear 3”-4 1/8” Dia. A/R
