3120290 4-21
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
FIGURE 4-5. CONSOLE BOX ASSEMBLIES - PQ CONTROLLERS WITH PROP TELE (MACHINES
BUILT PRIOR TO SEPTEMBER 1991)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLIES - PQ CONTROLLERS
WITH PROP TELE (MACHINES BUILT PRIOR TO
SEPTEMBER 1991) Ref.
0236821
CONSOLE BOX ASSEMBLY (MACHINES WITH
RACINE VALVES AND WITHOUT CAPACITY
INDICATOR)
Ref. J
0236822
CONSOLE BOX ASSEMBLY (MACHINES WITH
RACINE VALVES WITH CAPACITY INDICATOR)
Ref. J
0237948
CONSOLE BOX ASSEMBLY (2WD MACHINES WITH
VICKERS VALVE AND WITHOUT CAPACITY
INDICATOR)
Ref. E
0237947
CONSOLE BOX ASSEMBLY (2WD MACHINES WITH
VICKERS VALVE AND WITH CAPACITY INDICATOR)
Ref. F
0238216
CONSOLE BOX ASSEMBLY (4WD MACHINES WITH
VICKERS VALVES AND WITHOUT CAPACITY
INDICATOR)
Ref. E
0238215
CONSOLE BOX ASSEMBLY (4WD MACHINES WITH
VICKERS VALVE AND WITH CAPACITY INDICATOR)
Ref. E
1 3251742 Lid, Console 1
2 1600094 Controller, PQ 3
7003737 Electrical Assembly 3
3 0720803 Bolt #8-32NC x 3/8” 12
4 4760800 Lockwasher #8 12
5 2560040 Knob, Controller (Swing) 1
6 2560038 Knob, Controller (Lift) 1
7 2560041 Knob, Controller (Drive) 1
8 2560039 Knob, Controller (Tele) 1
9 Decal - Capacity Options: 1
3251551
Decal - Capacity (Machines Without Capacity Indi-
cator)
2960006
Lens, Capacity Indicator (Machines With Capacity
Indicator)
10 3911014 Screw, Round Head #10-24NC x 7/8” 4
11 4771000 Starwasher #10 4
12 3311001 Nut #10-24NC 6
13 2920015 Lamp 1
14 4360274 Switch, Push Button 2
15 4060087 Shield, Switch A/R
16 4360202 Switch, Toggle 3
17 4360199 Switch, Toggle 3
18 Toggle Switch Options: 1
4360204 Machines With Racine Valves
4360200 Machines With Vickers Valves
19 4360141 Guard, Switch 1
20 4420038 Tape, Insulation 34 in.
21 0100001 Adhesive (Not Shown) A/R
22 0751006 Screw #10-24NC x 3/4” 15
23 3300177 Nut, Tinnerman 15
