SECTION 1 FRAME
FIGURE 1-3. OPTIONAL REAR STEER INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
OPTIONAL REAR STEER INSTALLATION
Ref.
0252288
REAR STEER INSTALLATION
Ref.
A
1
4130272
Spindle (LH)
1
2
4130271
Spindle (RH)
1
3
3422002
Kingpin
4
4
3841142
Tie-Rod
1
5
3300229
Nut, Jam 1 1/4”-12NF (LH Thread)
1
6
0560714
Block, Tie-Rod (LH Thread)
1
7
2160002
Fitting, Grease
2
8
3323002
Nut, Jam 1 1/4”-12NF (RH Thread)
1
9
0560605
Block, Tie-Rod (RH Thread)
1
10
1681555
Steer Cylinder Assembly (See Section 5 for
Breakdown)
1
11
3431622
Pin, Clevis
1
12
4712600
Flatwasher 1” Narrow
1
13
3450606
Pin, Cotter 3/6” x 1”
1
14
0630447
Bolt, Special
1
15
3312602
Nut, Jam 1”-8NC
3
16
0440091
Bearing, Thrust
3
17
0630425
Bolt, Special
2
18
4740391
Bearing, Thrust
2
19
0630083
Bolt, Special
8
20
4751600
Flatwasher 3/8”
8
21
4920096
Wire, Safety
4 ft/1.2m
22
0100011
Loctite #242 (Not Shown)
A/R
23
3780187
O-Ring (March 1994 to Present)
8
AXLE WELDMENT
Ref.
4844003
PRIOR TO JUNE 1994
Ref.
-
4844808
JUNE 1994 TO PRESENT
Ref.
-
101
Bushing, Bronze Options:
4
0961614
Prior to June 1994
0961850
June 1994 to Present
102
2160002
Fitting, Grease
5
103
Valve, Relief (Not Shown) Options:
4
Not Required
Prior to June 1994
4640812
June 1994 to Present
