Page 64
1-56
3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
7001918
Carrier Assembly (2780114 and 2780144 Hubs)
Ref.
N/A
Carrier Assembly (2780187 Hub)
Ref.
31
7001900
Carrier
1
32
Kit
Washer, Thrust
6
7007645
Washer, Thrust (2780187 Hub)
6
33
7001902
Roller, Needle
84
34
Kit
Spacer
3
7007646
Washer, Thrust (2780187 Hub)
3
35
7001904
Shaft, Pinion
3
36
Kit
Gear, Cluster
3
7010465
Gear, Cluster (2780187 Hub)
3
37
7001906
Rollpin
3
38
Kit
Washer, Thrust (2780052, 2780145, 2780140,
2780142 and 2780135 Hubs)
6
Not Required
Washer, Thrust (2780110, 2780040 and 2780114
Hubs)
0
7007648
Washer, Thrust (2780136, 2780144 and 2780187
Hubs)
6
Ring Gear Options:
Ref.
41
7000299
Gear, Ring (2780052, 2780145 and 2780110
Hubs)
1
Use 7010467
Gear, Ring (2780140, 2780142, 2780135,
2780040, 2780136, 2780114, 2780144 and
2780187 Hubs) (was p/n 7000279)
1
51
Kit
O-Ring
2
Use 7000218
Cover Assembly (was p/n 7000280)
Ref.
61
7000218
Cover
1
62
Kit
Cap, Cover
1
63
7000220
Bolt
4
64
Kit
Cap, Disconnect
1
65
Kit
Rod, Disconnect
1
66
Kit
O-Ring
1
67
Kit
O-Ring
1
68
Use 2200201
Plug (was p/n 7000243)
1
71
7000282
Washer
2
81
7000283
Spring
1
91
7000284
Ring, Retaining
1
101
7000285
Ring, Retaining
1
Input Shaft Options:
Ref.
111
7000292
Shaft, Input (2780052, 2780145, 2780140 and
2780142 Hubs)
1
7000222
Shaft, Input (2780110, 2780135, 2780040,
2780114, 2780144 and 2780187 Hubs)
1
7007649
Shaft, Input (2780136 Hub)
1
FIGURE 1-16. HUB ASSEMBLIES (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
