3120290 1-39
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-10. BRAKE ASSEMBLY - AUSCO AND MICO
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0920027
BRAKE ASSEMBLY - AUSCO AND MICO (2WD AND
4WD REAR WITH CESSNA MOTORS)
Ref. G
Note: Used with Racine Valves and Cessna Motors
built Prior to Mid 1987.
BRAKE ASSEMBLY - AUSCO Ref.
1 Kit Ring, Retaining 1
2 Kit Ring, Retaining 1
3 7000713 Bearing, Ball 1
4 7000714 Housing 1
7003010 Retainer, Spring 1
5 7000759 O-Ring 1
6 7000782 Spring, Compression 8
7 7000798 Spring, Compression 8
8 7000716 Shaft 1
9 7000717 Pin, Torque 2
10 7000718 Disc, Primary 1
11 7003006 Spring, Compression 6
12 7000732 Disc, Rotating 3
13 7000720 Disc, Stationary 3
14 7000721 Piston 1
15 Kit Ring, Back-Up 1
16 Kit O-Ring 1
17 Kit Ring, Back-Up 1
18 Kit O-Ring 1
19 7000796 Bleeder 1
20 7000727 Plate, Power 1
21 7000729 Lockwasher 4
22 7000730 Bolt 4
7003007 Bolt, Flanged 4
23 Kit Gasket 2
24 Not Used
25 Not used
— — — — — — — — — —
2900131 Seal Kit (Includes items 1, 2, 15, 16, 17, 18 and 24) 1
BRAKE ASSEMBLY - MICO Ref.
26 7007913 Cap Screw 4
27 7007912 Lockwasher 4
28 7007924 Pipe Plug 1
29 7007975 Cover 1
30 Kit Square Ring 1
31 Kit O-Ring 1
32 7007920 Bearing 1
33 Kit O-Ring 1
34 Kit Back-Up Ring 1
35 7007923 Piston 1
