SECTION 1 FRAME
FIGURE 1-19. CONTROL VALVE ASSEMBLY - 2 SECTION BANG-BANG (4WS)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
4640684
CONTROL VALVE ASSEMBLY - 2 SECTION BANG-
BANG (4WS)
Ref. -
1 7002315 Steer Section - Complete (Front and Rear) 2
2 7004859 Solenoid Assembly 2
3 7002274 Washer 1
4 7002348 Spring 1
5 7002305 Guide Tube Assembly 1
6 7002345 Cone, Female 1
Kit O-Ring 1
Kit O-Ring 1
7 7002346 Pin, Push 1
8 7002344 Plunger 1
9 7000470 Tube, Guide 1
10 7002341 Pin, Actuator 1
Kit Ring, Quad 1
11 7002340 Guide, External Push Pin 1
Kit O-Ring 1
12 700233 Sleeve, Inner Flux 1
13 7002334 Spring 1
14 7002336 Sleeve, Outer Flux 1
15 7000418 Coil 1
16 7002335 Case, Solenoid 1
17 7002338 Plate, End 1
7002327 Nameplate 1
18 7002339 Screw 4
19 7000468
Relief Valve Block Assembly (No Longer Field
Serviceable)
1
7000414 Seal Kit - Working Section 2
