Page 12
1-4
3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
2360382
Machines with Optional 4WS (June 1994 to Pres-
ent)
0236282
STEERING AND SPINDLES INSTALLATION - 60H,
60H+6 AND 70H STANDARD MACHINES BUILT
PRIOR TO MAY 1992
Ref.
M
0238261
STEERING AND SPINDLES INSTALLATION - 60H
WITH 750 LBS CAPACITY (DOMESTIC) AND 70H
CSA MACHINES BUILT PRIOR TO MAY 1992
Ref.
F
0251485
STEERING AND SPINDLES INSTALLATION - 60H
CSA MACHINES BUILT PRIOR TO MAY 1992
Ref.
D
0252377
STEERING AND SPINDLES INSTALLATION - 60H
STANDARD MACHINES BUILT MAY 1992 TO PRES-
ENT
Ref.
_
0252378
STEERING AND SPINDLES INSTALLATION - 60H
WITH 750 LBS. CAPACITY, 60H+6 AND 70H
STANDARD MACHINES BUILT MAY 1992 TO PRES-
ENT
Ref.
_
Note: Components for Machines with Towing
Package may vary, see Towing Package Installation.
1
1681562
Steer Cylinder Assembly (See Section 5 for
Breakdown)
1
2
3840734
Tie-Rod (RH Thread - Both Ends - Used Prior to May
1986)
1
3840866
Tie-Rod (RH/LH Thread - Used May 1986 to Present)
1
3
Not Used
4
3421153
King-Pin
2
5
0440161
Bearing, Thrust
4
6
Seal, Hub Options:
2
3960098
Standard Machines
3960343
Machines With 750 Capacity
7
3300007
Nut, Wheel 3/4”-16NF
20
8
0630078
Stud, Wheel 3/4”-16NF x 2 1/4” (Part of Hub
Assembly)
20
9
Hub Assembly Options:
2
0235017
Standard Machines
2780109
Machines With 750 Capacity (Prior to May 1992)
2780188
Machines With 750 Capacity (May 1992 to Pres-
ent)
10
Cap, Hub Options:
2
1120032
Standard Machines
1120304
Machines With 750 Capacity
11
0721003
Bolt #10-24NC x 3/8”
6
12
4761000
Lockwasher #10
6
13
Washer, Hardened Options:
2
4740016
Standard Machines
4740283
Machines With 750 Capacity
14
3323403
Nut, Slotted 1 1/2”-12NF
4
15
3451012
Pin, Cotter 5/16” x 3”
2
FIGURE 1-1. FRAME AND STEERING INSTALLATION - 2WD (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
