3120290 5-15
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
FIGURE 5-5. PLATFORM LEVEL CYLINDER ASSEMBLIES (MODEL 60H AND 70H BUILT PRIOR TO
DECEMBER 1986)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLIES Ref.
1681518 PRIOR TO NOVEMBER 1984 Ref. C
1681548 NOVEMBER 1984 TO DECEMBER 1986 Ref. F
1 Barrel Assembly Options: 1
1680722 Prior to November 1984
1680731 November 1984 to December 1986
2 16801331 Rod Assembly 1
0960097 Bushing 1
3 Head Options: 1
1680892 Prior to November 1984
1681635 November 1984 to December 1986
4 1120179 Retainer 1
5 1440142 Spacer 1
6 Piston Options: 1
Not Available
Piston (Prior to Mid 1989) (See Note Illustration
Page)
3480120 Piston (Mid 1989 to December 1986)
7 3300101 Nut 1
8 Valve, Cartridge Options: A/R
4640269 Valve, Cartridge (Prior to November 1984) 1
4640495
Valve, Cartridge (November 1984 to December
1986)
2
2900770 Seal Kit - 4640495 Valve (1 Per Cartridge) 2
9 Kit Seal, Wiper 1
10 Kit Seal, Rod 1
11 Kit Ring, Wear 1
12 Kit O-Ring 1
13 Kit Ring, Back-up 2
14 Kit Ring, Wear 1
15 Kit Seal, Piston 1
16 Kit O-Ring 1
17 0100011 Loctite #242 A/R
18 2160001 Fitting, Grease - 90° 1
19 2200213 Plug, Pipe - 3/8” 2
20 0100020 Sealant, Pipe A/R
21 0100021 Primer, Locking A/R
22 2200201 Plug, Pipe 1/8” 2
— — — — — — — — — —
2901119 Seal Kit - 1681518 Cylinder (Includes Items 9-16) 1
2901120 Seal Kit - 1681548 Cylinder (Includes Items 9-16) 1
