1-18 3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
54 3160110
Drive Motor Assembly (See Figure 1-6 for
Breakdown)
2
55 0641844 Bolt 1/2”-13NC x 5 1/2” (Not Shown) 4
56 4761800 Lockwasher 1/2” 4
57 0642016 Bolt 5/8”-11NC x 2” 16
58 4762000 Lockwasher 5/8” 16
59 Not Required
60 4751800 Flatwasher 1/2” 4
WHEEL DRIVE INSTALLATION - 4WD MACHINES
WITH VICKERS MOTORS USED WITH VICKERS
VALVES (MACHINES BUILT 1987 TO MAY 1992)
Ref.
0238301
WHEEL DRIVE INSTALLATION - 60H 4WD FRONT
DRIVE WITH VICKERS MOTORS
Ref. C
0238315
WHEEL DRIVE INSTALLATION - 60H 4WD REAR
DRIVE WITH VICKERS MOTORS
Ref. D
0238302
WHEEL DRIVE INSTALLATION - 70H 4WD FRONT
DRIVE WITH VICKERS MOTORS
Ref. C
0238316
WHEEL DRIVE INSTALLATION - 70H 4WD REAR
DRIVE WITH VICKERS MOTORS
Ref. C
101 Not Used
Hub Assembly - 53.58:1 Ratio (See Figure 1-16 for
Breakdown)
2
102 3300007 Lugnut 3/4”-16NF 20
103 Brake Assembly Options: 2
0920072
Machines Built Prior to March 1992 (See
Figure 1-13 for Breakdown)
0920084
Machines Built March 1992 to S/N 33476 (See
Figure 1-14 for Breakdown)
0920110
Machines Built S/N 33476 to Present (See
Figure 1-14 for Breakdown)
104 Motor Assembly - Vickers Options: 2
3160123 Front (See Figure 1-7 for Breakdown)
3160140 Rear (See Figure 1-8 for Breakdown)
105 4300092 Stud 1/2”-13NC x 5 1/2” 4
106 4761800 Lockwasher 1/2” 4
107 0642016 Bolt 5/8”-11NC x 2” 16
108 4762000 Lockwasher 5/8” 16
109 3311801 Nut 1/2”-13NC 4
110 4751800 Flatwasher 1/2” 4
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
