SECTION 1 FRAME
210 2160002 Fitting, Grease (Straight) A/R
211 2160001 Fitting, Grease (90°) 4
212 Not Used
213 4070796 Shim, Axle (LH) 3
214 3537016 Plate, Stop 2
215 4070795 Shim, Axle (RH) 3
216 3311501 Nut 5/16”-18NC 4
217 4761500 Lockwasher 5/16” 4
218 4751500 Flatwasher 5/16” 4
Note: Items 219-223 Fixed Axle Only.
219 4844258 Stop, Axle 2
220 3951611 Setscrew 3/8”-16NC x 1 3/8” 4
221 3311602 Nut, Jam 3/8”-16NC 4
222 0641508 Bolt 5/16”-18NC x 1” 4
223 4070812 Shim, Stop (1/16”) A/R
4070813 Shim, Stop (1/4”) A/R
4070814 Shim, Stop (1/8”) A/R
4070815 Shim, Stop (3/8”) A/R
0100011 Loctite #242 A/R
0236283 FRAME SHIELDS INSTALLATION Ref.
0236732 FRAME SHIELDS INSTALLATION Ref.
0238923 FRAME SHIELDS INSTALLATION Ref.
0238924 FRAME SHIELDS INSTALLATION Ref.
0252389 FRAME SHIELDS INSTALLATION Ref.
0252390 FRAME SHIELDS INSTALLATION Ref.
301 Front Frame Shields Options: 1
4060573 Fixed Axle Machines Built Prior to May 1992
4060594 Oscillating Axle Machines Built Prior to April 1985
4060607
Oscillating Axle Machines Built April 1985 to May
1992
1670618 All Machines Built May 1992 to Present
302 4761400 Lockwasher 1/4” 8
303 3300151 Nut, Acorn 1/4”-20NC 8
304 4300031 Stud (Welded on Part) 8
305 Rear Frame Shield Options: 1
4060573 Fixed Axle Machines Built Prior to may 1992
4060573 Oscillating Axle Machines Built Prior to April 1985
4060606
Oscillating Axle Machines Built April 1985 to May
1992
1670619 4WS Machines Only Built May 1992 to Present
FIGURE 1-1. FRAME AND STEERING INSTALLATION - 2WD (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
