SECTION 1 FRAME
FIGURE 1-7. DRIVE MOTOR ASSEMBLY - VICKERS (4WD FRONT).
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160123 DRIVE MOTOR ASSEMBLY - VICKERS (4WD FRONT) Ref. _
Note: Used with Vickers Valves Built 1987 to 1982
1 7006701 Screw 4
2 7006702 Block, Valve 1
3 7006722 Housing 1
4 7006704 Bearing and Race 1
5 7006705 Wafer Plate 1
6 7006706 Pin 1
7 7006707 Spacer 1
8 7006712 Cylinder Block 1
9 7006717 Piston and Shoe 9
10 7006716 Shoe Plate 1
11 7006715 Washer, Spherical 1
12 7006713 Pin 3
13 7006714 Retainer Pin 1
14 7006708 Ring, Retaining 1
15 7006709 Washer 1
16 7006710 Spring 1
17 7006711 Washer, Thrust 1
18 7006720 Pin Alignment 2
19 7006718 Swash Plate 1
20 7006700 Shaft 1
21 7006719 Bearing and Race 1
22 7006721 Ring, Retaining 1
23 7006703 Plug 1
24 7006796 Seal, Shaft 1
— — — — — — — — — —
7006723
Kit, Rotating Group (Includes Items 8 through 17 and
Item 19)
1
2900595 Kit, Seal (Includes Gasket, Shaft Seal and Plug O-Ring) 1
