FIGURE 5-7. PLATFORM LEVEL CYLINDER ASSEMBLIES (MODEL 60H AND 70H BUILT APRIL
1992 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLY Ref.
1682602 Prior to S/N 33111 Ref. B
1683534 S/N 33111 to Present Ref. 1
1 Barrel Assembly Options: 1
1682603 Prior to S/N 33111
1683533 S/N 33111 to Present
2 1681331 Rod Assembly 1
0960097 Bushing 1
3 1680892 Head 1
4 3480120 Piston 1
5 4564046 Spacer 1
6 3300272 Nut 1
7 1120179 Retainer 1
8 Kit Seal, Wiper 1
9 Kit Seal, Rod 1
10 Kit Ring, Wear 1
11 Kit O-Ring 1
12 Kit Ring, Back-up 2
13 Kit Ring, Wear 1
14 Kit O-Ring 1
15 Kit Seal, Piston 1
16 2160002 Fitting, Grease 2
17 4640634 Valve, Cartridge - Holding 2
2900770 Seal Kit - 4640634 Valve (1 Per Assembly) 1
18 3900170 Setscrew 3/8”-16NC x 3/8” 1
19 2220885 Plug, Socket Head #6 2
20 0100011 Loctite #242 A/R
21 0100038 Primer, Locking A/R
22 0100035 Loctite #222 A/R
— — — — — — — — — —
2900381 Seal Kit - (Includes Items 8-15) 1
