JLG 70H Parts Manual User Manual
Page 320
4-22
3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
24
3960240
Weatherstrip
16”
25
0100009
Silicone - RTV (Not Shown)
A/R
26
0860472
Box Weldment
1
27
4460263
Strip, Terminal
1
28
3911012
Screw, Round Head #10-24NC x 3/4”
2
29
4761000
Lockwasher #10
6
30
3960251
Gasket
1
31
3300048
Locknut, Conduit
2
32
4460071
Connector, Strain Relief
1
33
4460051
Connector, Strain Relief
1
34
3300047
Locknut, Conduit
1
35
4460052
Connector, Strain Relief
1
36 to 40
Not Used
41
0100011
Loctite #242 (Not Shown)
A/R
42
3311405
Locknut 1/4”-20NC
4
43
3509858
Plate, Rear Cover
1
44
4751400
Flatwasher 1/4”
8
45
0641407
Bolt 1/4”-20NC x 7/8”
4
46
3790012
O-Ring
A/R
47
0860038
Box, Receptacle
1
48
Not Used
49
4460049
Connector, Strain Relief
1
50
4460190
Receptacle
1
51
4060092
Shield, Weatherproof
1
52
3911008
Screw, Machine #10-24NC x 1/2”
4
53
0960407
Bushing
1
54
Not Used
55
4360209
Breaker, Circuit - 20 Amp
1
56
3321001
Nut #10-32NF
2
57
4751000
Flatwasher #10
2
58
Switch, Toggle (Wheel Speed) Options:
1
Not Required
Machines with Racine Valves
4360199
Machines with Vickers Valves
59
Controller, PQ Options:
1
1600094
2WD - Controller, PQ
7003737
Electrical Assembly
1
1600095
4WD -Controller, PQ
7003746
Electrical Assembly
1
60
Switch, Toggle(2WD/4WD) Options:
1
Not Required
2WD Machines
4360199
4WD Machines
OPTIONAL INSTALLATIONS
Ref.
101
Glow Plug Control Components (Location may vary)
4360200
Switch, Toggle
1
4060087
Shield, Switch
1
3790012
O-Ring
1
102
Beacon Lights Controls Components
FIGURE 4-5. CONSOLE BOX ASSEMBLIES - PQ CONTROLLERS WITH PROP TELE (MACHINES
BUILT PRIOR TO SEPTEMBER 1991) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
