Page 25
3120290
1-17
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
WHEEL DRIVE INSTALLATION - MACHINES WITH
CESSNA SINGLE SPEED MOTORS (USED WITH
RACINE VALVES/MACHINES BUILT PRIOR TO EARLY
1987)
0236825
WHEEL DRIVE INSTALLATION - 60H 2WD WITH
CESSNA SINGLE SPEED MOTORS
Ref.
-
0236840
WHEEL DRIVE INSTALLATION - 70H 2WD WITH
CESSNA SINGLE SPEED MOTORS
Ref.
A
0236839
WHEEL DRIVE INSTALLATION - 60H/70H 4WD
FRONT WITH CESSNA SINGLE SPEED MOTORS
Ref.
B
0236264
WHEEL DRIVE INSTALLATION - 60H/70H 4WD
REAR WITH CESSNA SINGLE SPEED MOTORS
Ref.
E
1
3160104
Drive Motor Assembly - Cessna Single Speed (See
Figure 1-5 for Breakdown)
2
2
Brake Assembly Options:
2
0920027
60H & 70H 2WD With Cessna Single Speed
Motors (See Figure 1-10 for Breakdown)
0920068
60H & 70H 4WD Front With Cessna Single Speed
Motors (See Figure 1-11 for Breakdown) (Used
Prior to August 1991)
0920086
60H & 70H 4WD Front With Cessna Single Speed
Motors (See Figure 1-12 for Breakdown) (Used
August 1991 to Present and for Service Replace-
ment Requirements)
0920027
60H & 70H 4WD Rear With Cessna Single Speed
Motors (See Figure 1-10 for Breakdown)
3
0641844
Bolt 1/2” - 13NC x 5 1/2”
4
4
4761800
Lockwasher 1/2”
4
5
Hub Assembly Options (See Figure 1-16 for Break-
down):
2
2780110
Hub Assembly - 30:1 Ratio (60H 2WD With
Cessna Single Speed Motors)
2780136
Hub Assembly - 43:1 Ratio (70H 2WD With
Cessna Single Speed Motors)
2780135
Hub Assembly - 35:1 Ratio (60H & 70H 4WD Front
With Cessna Single Speed Motors)
2780040
Hub Assembly - 35:1 Ratio (60H & 70H 4WD Rear
With Cessna Single Speed Motors)
6
0642016
Bolt 5/8”-11NC x 2”
16
7
4762000
Lockwasher 5/8”
16
8
3300007
Lugnut 3/4”-16NF
20
0236663
WHEEL DRIVE INSTALLATION - MACHINES WITH
CESSNA TWO SPEED MOTORS (USED WITH
RACINE VALVES/OPTIONAL ON MACHINES BUILT
PRIOR TO EARLY 1987)
Ref.
A
51
2780114
Hub Assembly - 53.58:1 Ratio (See Figure 1-16 for
Breakdown)
2
52
3300007
Lugnut 3/4”-16NF
20
53
0920027
Brake Assembly (See Figure 1-10 for Breakdown)
2
