3120290 5-29
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
FIGURE 5-11. TELESCOPE CYLINDER ASSEMBLY (MODEL 60H AND 60H+6)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1681516
TELESCOPE CYLINDER ASSEMBLY (MODEL 60H
AND 60H+6)
Ref. G
1 1681349 Barrel Assembly 1
2 1681350 Rod Assembly 1
3 4562573 Spacer 1
4 Not Used
5 Not Used
6 1120108 Retainer 1
7 3480054 Piston 1
8 Nut Options: 1
3300086 Nut (Prior to January 1991)
3300293 Nut, Hex (January 1991 to Present)
9 Kit Ring, Wear 2
10 Kit Seal, Rod 1
11 Kit Seal, Wiper 1
12 2200102 Plug, Pipe 1/4” 4
13 4640212 Valve, Cartridge - Holding 1
2900793 Seal Kit - 4640212 Valve 1
14 Kit T-Seal 1
15 Kit T-Seal 1
16 Kit O-Ring 1
17 1681307 Head 1
18 Kit Ring, Wear 1
19 0100011 Loctite #242 A/R
20 3951405 Setscrew 1/4”-20NC x 5/8” 1
21 4420001 Tape, Sealant A/R
22 2200221 Plug, Pipe 1/8” 1
23 3900171 Setscrew 1
24 0100035 Compound, Locking A/R
25 Not Used
26 0100038 Primer, Locking A/R
— — — — — — — — — —
2900350
Seal Kit - 1681516 Cylinder (Includes Items
9,10,11,14,15,16 and 18)
1
