3120290 1-33
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-8. DRIVE MOTOR ASSEMBLY - VICKERS (2WD AND 4WD REAR)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160140 DRIVE MOTOR ASSEMBLY - VICKERS (4WD REAR) Ref. A
3160132 DRIVE MOTOR ASSEMBLY - VICKERS (2WD REAR) Ref. B
Note: Used with Vickers Valves Built 1987 to May
1992.
1 7006766 Yoke 1
2 7006767 Roll Pin 1
3 7006768 Spherical Seat 1
4 Seat, Spring Options: 1
7006772 4WD Rear
7006769 2WD Rear
5 7006774 Yoke Spring 1
6 7006776 Yoke Stop 1
7 Kit Gasket 1
8 7006786 Housing 1
9 7006787 Washer 6
10 7006788 Screw 6
11 7006789 Screw 4
12 Shim (Included in Kit 7006794) 1
13 7006721 Retaining Ring 1
14 Not Used
15 7006791 Bearing 2
16 7006792 Printle Bearing 2
17 Kit O-Ring 2
18 7006794 Shim Kit 1
19 7006795 Cover 2
20 7006719 Bearing 1
21 7006797 Piston 1
22 7006798 Piston Rod 1
23 7006703 Plug 1
24 Kit O-Ring 1
25 7009300 Screw 4
26 7009301 Control Block 1
27 Kit Gasket 1
28 Kit O-Ring 1
29 Kit Back-Up Ring 1
30 7009305 Retaining Ring 1
31 7009306 Valve Block 1
32 7006706 Pin 1
33 7009307 Pin 2
34 7009308 Shaft 1
35 7006717 Piston and Shoes 9
36 7006716 Shoe Plate 1
37 7006715 Spherical Washer 1
38 7006714 Pin, Retainer 1
39 7006713 Pin 3
40 7006712 Cylinder, Block 1
41 7006711 Spring Washer 1
