JLG 70H Parts Manual User Manual
Page 264
2-186
3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
208
2420009
Hourmeter
1
209
0641408
Bolt 1/4”-20NC x 1”
6
210
4761400
Lockwasher 1/4”
16
211
3311401
Nut 1/4”-20NC
13
212
4300031
Stud (Welded on Part)
5
213
2600094
Hinge
1
214
0100011
Loctite #242 (Not Shown)
A/R
GAUGES INSTALLATION (FROM ENGINE
INSTALLATION) (VARIABLE PARTS)
Ref.
271
Oil Pressure Gauge Options:
1
2420030
Deutz Powered Machines
2420035
Ford Powered Machines - Prior to August 1994 and
February 1995 to Present
2420164
Ford Powered Machines - August 1994 to
February 1995
Consult Factory
Wisconsin Powered Machines
272
2420001
Fitting, Swivel
1
273
2200261
Fitting, Coupling
1
274
Hose Options:
A/R
Consult Factory
Ford and Deutz Powered Machines
2750527
Wisconsin Powered Machines
275
Temperature Gauge Options:
A/R
Not Required
Deutz Powered Machines
2420019
Ford Powered Machines - Prior to August 1994 and
February 1995 to Present
2420159
Ford Powered Machines - August 1994 to February
1995
Not Required
Wisconsin Powered Machines
FIGURE 2-43. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH VICKERS
PROPORTIONAL VALVES) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
