1-6 3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
0236747
OPTIONAL OSCILLATING AXLE INSTALLATION
(MACHINES BUILT PRIOR TO MAY 1992)
Ref. E
101 1681569
Axle Lockout Cylinder Assembly (See Section for
Breakdown)
2
102 4842178 Front Axle Weldment 1
0980069 Bushing, Bronze 2
103 0641838 Bolt 1/2”-13NC x 4 3/4” 1
104 3311805 Locknut 1/2”-13NC 1
105 3421220 Pin, Clevis 2
106 3450607 Pin, Cotter 3/16” x 1 3/4” 4
107 2160002 Fitting, Grease 6
108 3451214 Pin, Cotter 3/8” x 3 1/2” 1
109 3421273 Pin 1
110 3421219 Pin Weldment 2
111 0641606 Bolt 3/8”-16NC x 3/4” 2
112 Not Used
113 0440163 Bearing, Thrust 2
114 4740110 Flatwasher 4
115 4070539 Shim, Axle A/R
116 4220099 Stop, Axle 2
117 4300034 Stud (Welded on Part) 4
118 4751600 Flatwasher 3/8” 5
119 4761600 Lockwasher 3/8” 6
120 3311601 Nut 3/8”-16NC 4
121 4300048 Stud (Welded on Part) 4
122 4751800 Flatwasher 1/2” 5
123 4761800 Lockwasher 1/2” 4
124 3311801 Nut 1/2”-18NC 4
0252380
FRONT AXLE INSTALLATION (FIXED AXLE
MACHINES BUILT MAY 1992 TO PRESENT)
Ref. B
0252381
FRONT AXLE INSTALLATION (OSCILLATING AXLE
MACHINES BUILT MAY 1992 TO PRESENT)
Ref. C
Note: Components for Machines with Towing Pack-
age may vary, see Towing Package Installation.
201 4844037 Axle Weldment 1
0961613 Bushing, Bronze 2
3780188 O-Ring 2
202 3421995 Pin, Pivot 1
203 0641832 Bolt 1/2”-18NC x 4” 1
204 4761800 Lockwasher 1/2” 1
205 3311801 Nut 1/2”-18NC 1
Note: Items 206-209 Oscillating Axle Only.
206 1682688
Axle Lockout Cylinder Assembly (See Section 5 for
Breakdown)
2
207 3421996 Pin, Attach (Upper) 2
208 3421997 Pin, Attach (Lower) 2
209 3760133 Ring, Retaining 8
FIGURE 1-1. FRAME AND STEERING INSTALLATION - 2WD (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
