JLG 70H Parts Manual User Manual
Page 78
1-70
3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
66
3450606
Pin, Cotter (4WD Machines Only)
1
67
0642620
Bolt 1” - 8NC x 2 1/2” (4WD Machines Only)
1
68
1660114
Tie-Rod (4WD Machines Only)
1
69
3312602
Nut, Jam 1”-8NC (4WD Machines Only)
3
70
0630425
Bolt, Special (4WD Machines Only)
1
71
4130294
Spindle (RH) (Use Standard Spindle for Left Side)
(4WD Machines Only)
1
72
3780187
O-Ring (Not Shown - Located near Kingpin) (June
1994 to Present) (4WD Machines Only)
4
0253188
FRONT AXLE INSTALLATION - MACHINES BUILT
MAY 1992 TO PRESENT ONLY (2WD FIXED AXLE)
Ref.
B
0253191
FRONT AXLE INSTALLATION - MACHINES BUILT
MAY 1992 TO PRESENT ONLY (2WD OSCILLATING
AXLE)
Ref.
A
0253706
FRONT AXLE INSTALLATION - MACHINES BUILT
MAY 1992 TO PRESENT ONLY (4WD)
Ref.
A
Note: Machines built prior to May 1992 use
standard axle with welded on parts called out in 1-
49 series numbers.
80
Axle Weldment Options:
1
4844231
2WD Axle
0961613
Bushing, Bronze
2
4844366
4WD Axle (May 1992 to June 1994)
0961613
Bushing, Bronze (Axle Pivot)
2
0961614
Bushing, Bronze (Kingpin)
4
4844809
4WD Axle (June 1994 to Present)
0961613
Bushing, Bronze (Axle Pivot)
2
0961850
Bushing, Bronze (Kingpin)
4
0236880
TOW BAR ASSEMBLY AND STOWAGE INSTALLA-
TION (FIXED AXLE BUILT PRIOR TO MAY 1992)
Ref.
-
0236968
TOW BAR ASSEMBLY AND STOWAGE INSTALLA-
TION (OSCILLATING AXLE BUILT PRIOR TO MAY
1992)
Ref.
-
0253196
TOW BAR ASSEMBLY AND STOWAGE INSTALLA-
TION (60H BUILT MAY 1992 TO PRESENT)
Ref.
-
0253197
TOW BAR ASSEMBLY AND STOWAGE INSTALLA-
TION (70H BUILT MAY 1992 TO PRESENT)
Ref.
-
101
0232121
Tow Bar Assembly
1
3420447
Pin, Tow
1
4740036
Flatwasher, Special
1
3420372
Pin, Cotter
1
102
4841055
Mount, Stowage
2
103
3420292
Pin, Quick Release
2
104
1260017
Chain (2PC x 4”)
8”
105
4300031
Stud (Welded on Part)
2
106
4751400
Flatwasher 1/4”
2
107
3311405
Locknut 1/4”-20NC
2
FIGURE 1-20. TOW PACKAGE INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
