3120290 3-9
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
0236044
CHAIN ADJUSTER ASSEMBLY (REFER TO ITEM 83
FOR USAGE)
Ref. B
0236294
CHAIN ADJUSTER ASSEMBLY (REFER TO ITEM 48
FOR USAGE)
Ref. D
201 3509182 Plate 2
202 Not Used
203 0630374 Eyebolt 1
204 Block, Chain Attach Options: 2
0560554 Chain Adjuster Assembly - 0236044
0560588 Chain Adjuster Assembly - 0236294
205 0630347 Bolt 1/2”-13NC x 2 1/4” (Grade 8) 2
206 3450405 Pin, Cotter 1/8” x 1 1/4” 2
207 3311803 Nut, Slotted 1/2”-13NC 2
208 3421142 Pin, Clevis 3/4” x 2” 1
209 3450505 Pin, Cotter 5/32” x 1 1/4” 1
210 4712200 Flatwasher 3/4” Narrow 1
1280732 BOOM TAPE INSTALLATIONS Ref. H
301 4420018 Tape - Blue A/R
60H Standard Spec 119 in.
60H CSA/2:1 Stability Spec 108 in.
70H Standard Spec 147 in.
70H CSA/2:1 Stability Spec 137 in.
302 4420016 Tape - Yellow A/R
60H Standard Spec 27 in.
60H CSA/2:1 Stability Spec 33.5 in.
70H Standard Spec 33.5 in.
70H CSA/2:1 Stability Spec 37 in.
303 4420017 Tape - Red A/R
60H Standard Spec 42 in.
60H CSA/2:1 Stability Spec 47 in.
70H Standard Spec 45.5 in.
70H CSA/2:1 Stability Spec 52 in.
0236631 STEERING TUBE INSTALLATION Ref. B
401 4340447 Support, Tube (Left Side) 3
402 4300036 Stud (Not Shown - Use with Item 401) 6
403 3311401 Nut 1/4”-20NC (Not Shown - Use with Item 401) 6
404 4751400 Flatwasher 1/4” (Not Shown - Use with Item 401) 6
405 4761400 Lockwasher 1/4” (Not Shown - Use with Item 401) 6
406 4060568 Shield (Left Side - Front) 1
407 4842120 Crossover Weldment 1
408 4060699 Shield (Left Side - Rear) 1
FIGURE 3-1. BOOM COMPONENT ASSEMBLIES (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
