JLG 70H Parts Manual User Manual
Page 308
4-10
3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
18
Lockwasher 3/8” Options:
1
4761600
60H/70H
Not Required
60H+6
19
2160002
Fitting, Grease
A/R
20
Not Used
21
Pin Options:
1
Not Required
60H/70H
60H+6 Options:
3421426
Pin (Prior to March 1991)
3421825
Pin (March 1991 to November 1991)
3422019
Pin (November 1991 to Present)
22
4740158
Washer, Thrust
1
23
0641404
Bolt 1/4”-20NC x 1/2”
1
24
4761400
Lockwasher 1/4”
2
25
4751400
Flatwasher 1/4”
2
26
0641408
Bolt 1kl/4”-20NC x 1”
1
27
4562083
Spacer, Tube
1
28
Pin Options:
1
3421176
60H/70H
Not Required
60H+6
29
Cover Options:
1
60H/70H Options:
1670322
Cover (Prior to July 1990)
1670519
Cover (July 1990 to April 1992)
1670630
Cover (April 1992 to Present)
60H+6 Options:
1670421
Cover (Prior to November 1992)
1670630
Cover (November 1992 to Present)
30
0641811
Bolt 1/2”-13NC x 1 3/8”
2
31
1380137
Clip, Retainer
2
32
Not Used
33
4920986
Wire, Mechanics
A/R
34
Retainer Options:
1
Not Required
60H/70H
60H+6 Options:
Not Required
(Prior to March 1991)
4740385
Washer (March 1991 to November 1991)
0362079
Bar (November 1991 to Present)
35
Hardware Options:
A/R
Not Required
60H/70H
3900159
60H+6 - Screw, Countersunk 1/2”-13NC x 3/4”
(Used March 1991 to Present)
1
0100011
Loctite #242
A/R
36
Not Used
37
Hardware Options:
A/R
Not Required
60H/70H
0641405
60H+6 - Bolt 1/4”-20NC x 5/8”
1
38
Hardware Options:
A/R
Not Required
60H/70H
3760237
60H+6 - Ring, Retainer (Used Prior to March 1991)
1
FIGURE 4-2. LOW MOUNT PLATFORM AND FOOTSWITCH INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
