3120290 1-25
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-5. DRIVE MOTOR ASSEMBLY - CESSNA (SINGLE SPEED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160104
DRIVE MOTOR ASSEMBLY - CESSNA (SINGLE
SPEED)
Note: Used With Racine Valves Built Prior To Mid
1987.
Ref A
1 Kit Ring, Retaining 1
2 Kit Seal, Shaft 1
3 7007594 Housing Assembly (With Bearing) 1
4 7007593 Bearing 1
5 7007595 Race, Bearing 1
6 7007596 Bearing, Thrust 1
7 7007597 Piston Race Assembly 1
8 7007598 Pivot 1
9 7007599 Spacer 1
10 7007814 Kit, Piston Replacement 1
11 7007800 Block, Piston 1
12 Not Used
13 7007801 Key 1
14 7007802 Shaft, Drive 1
15 7007803 Ring, Retaining 1
16 7007804 Spring 1
17 7007805 Pilot 1
18 7007806 Spider 1
19 7007807 Kit, Piston Replacement 1
20 7007808 Plate, Connector 1
21 7007809 Race, Thrust 2
22 7007810 Bearing, Thrust 1
23 Kit O-Ring 1
24 7007812 Back Plate Assembly (With Bearing) 1
25 7007593 Bearing 1
26 7007813 Bolt, Socket Head 6
— — — — — — — — — —
2900627 Seal Kit (Includes Items 1,2 and 23) 1
