Page 302
4-4
3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
0236831
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H/70H (DOMESTIC/STANDARD)
Ref.
G
0251459
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H/70H (CSA/2=1 STABILITY)
Ref.
4
0237672
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H+6 (DOMESTIC/STANDARD)
Ref.
5
0251488
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H+6 (CSA/2=1 STABILITY)
Ref.
5
101
Support Weldment Options:
1
0236261
60H/70H
4842609
60H+6
0960564
Bushing, Bronze
2
102
Pivot Weldment Options:
1
0236741
60H/70H
0961024
Bushing, Bronze
2
60H+6 Pivot Weldment Options:
0237975
Pivot (Prior to January 1991)
0251512
Pivot (January 1991 to Present)
0961185
Bushing, Bronze
2
103
1120299
Cap
1
104
Rotator Shaft Options:
1
4842046
Shaft (Standard/Domestic)
Use 4842046
Shaft (CSA/2:1 Stability) (was p/n 4040218)
105
0235238
Rotator Assembly (See Items 201-226 for
Breakdown)
1
106
Mount Options:
1
3200194
Mount (60H/70H)
0901411
Mount, Rotator (Not Shown) (60H+6)
107
3340454
Pad, Brake
2
108
4160026
Washer, Belleville
8
109
2880404
Key
1
110
0652014
Bolt 5/8”-18NF x 1 3/4”
1
111
4752000
Flatwasher 5/8”
1
112
0681610
Bolt 3/8”-16NC x 1 1/4” (Grade 8)
10
113
4751600
Flatwasher 3/8”
21
114
3300143
Locknut 3/8”-16NC
10
115
0641836
Bolt 1/2”-13NC x 4 1/2”
1
116
3311601
Nut 3/8”-16NC
1
117
2160002
Fitting, Grease
4
118
Pin Options:
1
3421176
60H/70H
Not Required
60H+6
119
4740158
Washer, Thrust
1
120
0641404
Bolt 1/4”-20NC x 1/2”
1
121
4761400
Lockwasher 1/4”
A/R
122
4751400
Flatwasher 1/4”
A/R
123
0641408
Bolt 1/4”-20NC x 1”
1
124
4562083
Spacer
1
125
0641811
Bolt 1/2”-13NC x 1 3/8”
2
FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
