1-22 3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
401 (cont’d) 0234746 4WD/4WS Right Front and Rear
Note: Assemblies may require ballast/foam filling
to manufacture’s specifications prior to installing
on a machine. Refer to Operation & Safety or Ser-
vice & Maintenance Manuals. Purchase individual
tire and/or rim only able to foam fill tire & wheel
assembly, otherwise, purchase complete assem-
bly.
4520178 Non-Marking Tire Option (Not Shown)
4520126 Solid Non-Marking Tire Option (Not Shown)
402 Rim Options:
0236539 Rim - 14”
4860108 Rim - 15” (Prior to S/N 43309)
4860148 Rim - 15” (S/N 43309 to Present)
Not Serviced Rim - Foam-Filled (Purchase Complete Assembly)
403 Stem, Valve Options:
4640113 Pneumatic
Not Serviced Foam-Filled
404
Decal - Tire Pressure Options (Not Shown Located
at Valve Stem):
1
1703504 Prior to S/N 34051
1702701 S/N 34051 to Present
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
