SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
7
Nut, Jam 1 1/4”-12NF Options:
2
3300023
2WD Oscillating Axle Machines Built Prior to May
1992
3300023
2WD Fixed Axle Machines Built Prior to May 1992
3323004
4WD Oscillating Axle Machines Built Prior to May
1992
8
4753000
Flatwasher 1 1/4”
2
9
Lug (Bottom) Options:
1
3040327
2WD Oscillating Axle Machines Built Prior to May
1992
Not Required
2WD Fixed Axle Machines Built Prior to May 1992
3530015
4WD Oscillating Axle Machines Built Prior to May
1992
10
Fitting, Grease Options:
1
2160003
Fitting, Grease - 45° (2WD Oscillating Axle
Machines Built Prior to May 1992)
2160003
Fitting, Grease - 45° (2WD Fixed Axle Machines
Built Prior to May 1992)
2160002
Fitting, Grease (4WD Oscillating Axle Machines
Built Prior to May 1992)
11
2880410
Keystock (Not Shown)
1
12
Tie-Rod Options:
1
3840822
Machines Oscillating Axle
3840643
Machines Fixed Axle
13
Gusset Options:
2
2550925
2WD Oscillating Axle Machines Built Prior to May
1992
Not Required
2WD Fixed Axle Machines Built Prior to May 1992
2551050
4WD Oscillating Axle Machines Built Prior to May
1992
14
1660114
Coupling
2
15
Lug (Steering Arm) Options:
1
3040314
2WD Oscillating Axle Machines Built Prior to May
1992
3040314
2WD Fixed Axle Machines Built Prior to May 1992
3040381
4WD Oscillating Axle Machines Built Prior to May
1992
Note: Items 16-23 Machines with Oscillating Axle
Only.
16
0900479
Bracket, Valve
1
17
4640261
Select Valve Assembly
1
18
0641507
Bolt 5/16”-18NC x 7/8”
2
19
4761500
Lockwasher 5/16”
2
20
4751500
Flatwasher 5/16”
2
21
3250840
Nameplate - Caution
1
22
3820001
Rivet
8
23
3250872
Nameplate - Tow Select
1
24
Nut, Special Options:
2
3300160
2WD Oscillating Axle Machines Built Prior to May
1992
3300160
2WD Fixed Axle Machines Built Prior to May 1992
FIGURE 1-20. TOW PACKAGE INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
