SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
324
4220044
Stop, Throttle
2
325
1320109
Clamp, Cable
1
326
4751600
Flatwasher 3/8”
1
327
4761600
Lockwasher 3/8”
1
328
3321601
Nut 3/8”-24NF
1
329
3580183
Pulley
1
330
1670340
Cover, Pulley
1
2420055
CAPACITY INDICATOR GAGE ASSEMBLY
Ref.
401
2420057
Housing
1
402
0440042
Bearing, Ball
2
403
4561774
Tube, Spacer
1
0255729
CAPACITY INDICATOR INSTALLATION -
DOMESTIC STANDARD PLATFORM
Ref.
-
0255730
CAPACITY INDICATOR INSTALLATION - CSA
STANDARD PLATFORM
Ref.
-
0255731
CAPACITY INDICATOR INSTALLATION -
0255732DOMESTIC LOW MOUNT PLATFORM
Ref.
-
0255732
CAPACITY INDICATOR INSTALLATION - CSA
LOW MOUNT PLATFORM
Ref.
-
501
Capacity Indicator Assembly Options (See Items
601-619 for Breakdown):
1
0255725
Domestic Standard Platform
0255726
CSA Standard Platform
0255727
Domestic Low Mount Platform
0255728
CSA Low Mount Platform
502
1670340
Cover
1
503
3580183
Pulley
1
0255725
CAPACITY INDICATOR ASSEMBLY - DOMESTIC
STANDARD PLATFORM
Ref.
A
0255726
CAPACITY INDICATOR ASSEMBLY - CSA
STANDARD PLATFORM
Ref.
A
0255727
CAPACITY INDICATOR ASSEMBLY - DOMESTIC
LOW MOUNT PLATFORM
Ref.
A
0255725
CAPACITY INDICATOR ASSEMBLY - CSA LOW
PLATFORM
Ref.
A
601
4845030
Box Assembly
1
602
Gauge, Capacity Indicator Options:
2420055
Domestic
1
2420050
CSA
1
603
4160058
Spring
1
604
3900111
Bolt, Shoulder
1
605
0100011
Loctite #242 (Not Shown)
A/R
606
4751400
Flatwasher 1/4”
2
607
3311405
Locknut 1/4”-20NC
2
608
4740362
Washer, Fender
2
FIGURE 4-9. CAPACITY INDICATOR INSTALLATION (OPTIONAL) (CONTINUED)
