SECTION 1 FRAME
FIGURE 1-6. DRIVE MOTOR ASSEMBLY - CESSNA TWO SPEED.
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160110 DRIVE MOTOR ASSEMBLY - CESSNA TWO SPEED Ref.
Note: Used with Racine Valves Built Prior to Mid 1987.
7004939 Control Piston Housing Assembly 1
1 7004938 Screw, Cap, Socket Head 4
2 7004940 Housing, Control Piston 1
3 Kit O-Ring 1
7004941 Backplate Assembly 1
4 7004933 Screw, Cap, Hex Head 4
5 7004942 Plug Assembly 1
6 7004943 Plug 1
7 Kit O-Ring 1
8 7004944 Plug Assembly (Shuttle Spool) 2
9 7004945 Plug 1
10 Kit O-Ring 1
11 7004946 Spool, Shuttle 1
12 Kit O-Ring 1
13 7004918 Washer, Back-up 1
14 7004917 Bearing, Needle 1
15 7004947 Backplate 1
16 7004937 Ring, Retaining 4
17 7004929 Pin, Connector 2
18 7004948 Control Piston Assembly 1
19 Kit Ring, Slippery 1
20 Kit O-Ring 1
21 7004949 Piston, Control 1
22 7004925 Spacer, Piston A/R
23 7004924 Spacer, Piston A/R
24 7004926 Spacer, Piston A/R
25 Kit Gasket, Housing 1
26 7004916 Rotating Kit Assembly 1
27 7004936 Ring, Retaining 1
28 7004950 Washer, Machined 2
29 7004951 Spring, Compression 1
30 7004952 Pin, Loading 3
31 7004953 Keeper, Pin 1
32 7004954 Piston, Assembly 9
33 7004955 Spider 1
34 7004956 Pivot 1
35 7004957 Washer, Wave 1
36 7004958 Block, Piston 1
37 7004928 Connector, Camplate 1
38 Kit Ring, Retaining 1
39 Kit Seal, Shaft 1
40 7004906 Washer 1
41 Kit Ring, Retaining 2
42 7004907 Race, Thrust 2
43 7004908 Bearing, Thrust 1
44 7004912 Shaft, Drive 1
