SECTION 9
RECOMMENDED SERVICE PARTS STOCK
MODELS 60H/60H+6/70 (STANDARD CONTROLS)
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
7012339
Coil - Vickers Valve (Figure 2-9)
1
2
2
7000417
Coil - Bang-Bang Valve (Dump) (Figure 2-11)
1
2
2
7002450
Coil - Bang-Bang Valve (Dump) (Figure 2-12)
1
2
2
7000418
Coil - Bang-Bang Valve (Working) (Figures 2-11, 2-12, 2-13
and 2-14)
1
2
2
7004214
Element, Air Filter (Figures 2-25)
1 doz.
1 doz.
1 doz.
3740067
Relay (Figures 2-25 and 2-32)
1
1
1
1340046
Breather, Tank (Figure 2-40)
2 per
machine
2 per
machine
2 per
machine
2120107
Element, Hydraulic Oil Filter (Figure 2-40)
2 per
machine
2 per
machine
2 per
machine
3740049
Relay - SPDT (Figures 2-43 and 4-6)
1
1
2
3740016
Relay - 3PDT (Figure 2-43)
1
1
2
4360186
Breaker, Circuit - 35 Amp (Figure 2-43)
1
1
2
4360069
Breaker, Circuit - 10 Amp (Figure 2-43)
1
1
2
4360466
Switch, Key (Figure 2-43)
1
1
2
2860030
Key (Figure 2-43)
2
4
6
4360199
Switch, Toggle (Figures 2-43 & 4-6)
1
1
2
4360274
Switch, Push Button (Figures 2-43 & 4-6)
1
1
2
4360202
Switch, Toggle (Figures 2-43 & 4-6)
1
1
2
4360201
Switch, Toggle (Figure 2-43)
1
1
2
4360200
Switch, Toggle (Figures 2-43 & 4-6)
1
1
2
4360057
Switch, LImit (Figure 2-45)
1
1
2
4360171
Switch, Tilt Indicator (Figure 2-45)
1
1
2
70003147
Power Track - Section Repair Kit (6 Links) (Figure 3-1)
2
2
2
2940006
Latch, Platform Door (Figures 4-1 and 4-2)
1
1
1
4360031
Footswitch (Figures 4-1 and 4-2)
1
1
1
4360209
Breaker, Circuit - 20 Amp (Figure 4-6)
1
1
2
1600141
Controller, PQ (Figure 4-6)
1
1
1
7011907
Electrical Assembly - 1600141 Controller (Figure 4-6)
1
2
2
4360475
Switch, Mushroom (Figure 4-6)
1
1
2
4360476
Block, Switch Contact (Figure 4-6)
1
1
2
3990010
Diode - 6 Amp (Figure 7-1)
4
6
8
VARIABLE PARTS
7029276
Filter, Engine Oil (Deutz) (Figure 2-25)
1 Case
1 Case
1 Case
7008828
Cable, Throttle (Deutz) (Figure 2-26)
1
1
1
7008829
Board, PC (Deutz) (Figure 2-26)
1
1
1
1600211
Control Module (Ford) (Figure 2-32)
1
1
1
3740059
Relay (Deutz) (Figure 2-25)
1
1
1
7012681
Module, Ignition (Ford) (Figure 2-32)
1
1
1
