JLG 70H Parts Manual User Manual
Page 165
3120290
2-87
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-24. DEUTZ ENGINE INSTALLATION WITHOUT NOISE REDUCTION (BUILT PRIOR TO
DECEMBER 1992)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
DEUTZ ENGINE INSTALLATION WITHOUT NOISE
REDUCTION (BUILT PRIOR TO DECEMBER 1992)
Ref.
0236375
DEUTZ F3L912 ENGINE ASSEMBLY - MACHINES
WITH RACINE PROPORTIONAL VALVES AND
SINGLE SPEED DRIVE
Ref.
G
0237287
DEUTZ F3L912 ENGINE ASSEMBLY - MACHINES
WITH RACINE PROPORTIONAL VALVES AND TWO
SPEED DRIVE
Ref.
D
0237997
DEUTZ F3L912 ENGINE ASSEMBLY - MACHINES
WITH VICKERS PROPORTIONAL VALVES AND
STANDARD ENGINE
Ref.
I
0238024
DEUTZ ENGINE ASSEMBLY - MACHINES WITH
VICKERS PROPORTIONAL VALVES AND CLEAN
BURN ENGINE
Ref.
G
0238022
DEUTZ F4L912 ENGINE ASSEMBLY - MACHINES
WITH VICKERS PROPORTIONAL VALVES AND
STANDARD ENGINE
Ref.
J
1
Engine Assembly Options:
1
2000066
Engine Assembly - F3L912 Standard
2000094
Engine Assembly - F3L912W Clean Burn
2000083
Engine Assembly - F4L912 Standard
2
Pump Assembly Options:
3600107
Machines with Racine Proportional Valves & Sin-
gle Speed Drive (See Figure 2-37 for Breakdown)
1
3600113
Machines with Racine Proportional Valves & Two
Speed Drive (See Figure 2-37 for Breakdown)
1
Machines with Vickers Proportional Valves
Options:
3600072
Pump with 1 Outlet in End Cover (Prior to Mid
1987) (See Figure 2-38 for Breakdown)
3600139
Pump with 2 Outlets in End Cover (Mid 1987 to
December 1992) (See Figure 2-39 for Break-
down)
3
4842079
Support, Motor (Front)
1
4
0181158
Support, Motor (Rear Left Side)
1
5
0181159
Support, Motor (Rear Right Side)
1
6
3200133
Mount, Engine (Front)
1
7
3200206
Bracket, Mounting (Front)
1
8
4842167
Bracket, Mounting (Rear)
2
9
Not Used
10
Not Used
11
Deflector Options:
1
4060580
Deutz F3L912 Engine
4060610
Deutz F4L912 Engine
12
1060044
Cable, Battery (Start Solenoid to Ground)
1
13
0641810
Bolt 1/2” - 18NC x 1 1/4”
2
14
4761800
Lockwasher 1/2”
2
