SECTION 1 FRAME
FIGURE 1-12. BRAKE ASSEMBLY - AUSCO 37845 (4WD FRONT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0920086 BRAKE ASSEMBLY - AUSCO 37845 (4WD FRONT) Ref. A
Note: Used with Racine Valves and Cessna Drive
Motors as a service replacement for 0920068 Brake.
1 7003092 Housing 1
2 Kit Gasket 1
3 7003049 Ball Bearing 1
4 7003050 Oil Seal 1
5 7003051 Spring Retainer 1
6 7003052 Compression Spring 12
7 7003093 Shaft 1
8 7003094 Torque Pin 2
9 7003054 Primary Disc 1
10 7003006 Compression Spring 2
11 7003055 Rotating Disc 1
12 7003056 Stationary Disc 1
13 7003095 Piston 1
14 Kit Backup Ring 1
15 Kit O-Ring 1
16 Kit Backup Ring 1
17 Kit O-Ring 1
18 7000760 Ball Bearing 1
19 7000796 Bleeder Screw 1
20 7003096 Power Plate 1
21 7003007 Hex Screw 4
22 7003059 Pressure Relief Valve 1
23 N.S. Plug Shipping 1
24 Kit Gasket 2
— — — — — — — — — —
2900662 O-Ring Kit (Includes items 2,14-17 and 24) 1
7003069 Gasket Kit (Includes Item 24) 1
