2-90 3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
Note: 3600115 Pump is no longer available -
use 3600071 Pump.
7013755 Replacement Motor 1
7004412 Replacement Coupling 1
Not Available
Replacement Pump (Purchase 3600071 Pump
Assembly)
1
Machines Built With Vickers Valves
3600052 Stone-Fenner Pump (Used Prior to Mid 1989)
7000483 Replacement Motor (Includes Coupling) 1
7004412 Replacement Coupling 1
7004416 Replacement Pump 1
2900164 Pump Seal Kit 1
3600071
Haldex/Barnes Pump (Used Mid 1989 to
December 1992)
7004248 Replacement Motor Only 1
7004436 Replacement Motor with Bracket 1
7012576 Replacement Mounting Bracket Only 1
7004249 Replacement Coupling 1
7004247 Replacement Pump 1
Not Available Pump Seal Kit 1
94 1060045 Cable, Battery (Aux. Relay to Start Relay) 1
95 1060149
Cable, Battery (Aux. Relay to Aux. Pump and Start
Relay to Starter)
2
96 2220001
Fitting, Swivel (Not Shown - Located at Ground
Control with Item 92)
1
97 2200261
Fitting, Coupling (Not Shown - Located at Ground
Control)
1
98 Return Line Fitting Options: 1
2220302 Machines Built With Racine Valves
Machines Built With Vickers Valves
2220317 Fitting (Prior to January 1991)
2180536 Fitting (January 1991 to December 1992)
99 Clamp Options: 1
Not Required Machines Built With Racine Valves
1320059 Machines Built With Vickers Valves
100 Clamp, Insulated Options: 3
Not Required Machines Built With Racine Valves
1320040 Machines Built With Vickers Valves
101
Fitting Options (Not Shown - Located at Ground Con-
trol with Item 92):
1
Not Required Machines Built With Racine Valves
2220124 Machines Built With Vickers Valves
0236850
ELECTRICAL PANEL ASSEMBLY (MACHINES
BUILT PRIOR TO JULY 1986)
Ref. E
201 3740059 Relay 1
202 3530425 Plate, Mounting 1
203 3740002 Relay 2
204 3740030 Relay, Adlo 1
FIGURE 2-24. DEUTZ ENGINE INSTALLATION WITHOUT NOISE REDUCTION (BUILT PRIOR TO
DECEMBER 1992) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
