3120290 6-13
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
S
SECTION 6 HYDRAULICS
FIGURE 6-5. HYDRAULIC DIAGRAM - LEVEL (60H+6 WITH ROTATING PLATFORM)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2792052
HYDRAULIC DIAGRAM - LEVEL (60H+6 WITH
ROTATING PLATFORM)
Ref. A
1 4640383 Valve, Restricter (.030) 2
2 4640216 Valve, Flow Control 2
3 4562719 Tube 2
4 4562916 Tube 1
5 4562532 Tube 1
6 4562531 Tube 1
7 4562914 Tube 1
8 2751904 Hose 2
9 2751862 Hose 2
10 2751830 Hose 2
11 2751856 Hose 2
12 2751833 Hose 2
13 2750997 Hose 1
14 2750919 Hose 1
15 2751444 Hose 2
16 2750785 Hose 1
17 2750998 Hose 2
18 0100011 Loctite A/R
19 2750990 Hose 2
20 2220371 Fitting, Straight 3
21 2220473 Fitting, 90° 1
22 2750910 Hose 1
23 2180379 Fitting 2
24 2180615 Fitting 2
25 2220591 Fitting 2
26 2220619 Fitting 2
27 2220343 Fitting 4
28 2220490 Fitting 2
29 2750779 Hose 1
30 2220507 Fitting 2
31 2220609 Fitting 2
32 2220497 Fitting 2
33 2220414 Fitting 2
34 2220446 Fitting 2
35 2220438 Fitting 2
36 2220399 Fitting 4
37 2220113 Fitting 3
38 2220280 Fitting 2
39 2220372 Fitting 1
40 2220385 Fitting 2
