JLG 70H Parts Manual - Manual (Page 122)

2-44 3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
135 Kit O-Ring (2 Per Section) A/R
136 Kit O-Ring (5 Per Section) A/R
137 Not Used
138 Not Serviced Cap, End (2 Per Section) A/R
— — — — — — — — — —
7009330 Seal Kit (1 Per Section) A/R
150 #1 WORKING SECTION OPTIONS: Ref.
7012356 Drive
151 7012355 Spool 1
152 7009399 Poppet 2
153 7012300 Piston 2
154 7012354 Spring 2
150 #2 WORKING SECTION OPTIONS: Ref.
7012334 Lift
151 7012331 Spool 1
152 7009397 Poppet 2
153 Not Required Piston 0
154 7006749 Spring 2
150 #3 WORKING SECTION OPTIONS: Ref.
7012334 Telescope
151 7012331 Spool 1
152 7009397 Poppet 2
153 Not Required Piston 0
154 7006749 Spring 2
150 #4 WORKING SECTION OPTIONS: Ref.
7012335 Swing
151 4640913 Spool 1
152 7009399 Poppet 2
153 7012300 Piston 2
154 7006749 Spring 2
OUTLET SECTION Ref.
201 7006782 Nut 6
202 7009329 Rod, Tie 3
203 7012337 Cover, End 1
204 Kit O-Ring 2
205 7006778 Plug 2
206 7012338 Setscrew Orifice Sub-Assembly 1
207 Kit O-Ring 1
208 7012336 Plug 1
FIGURE 2-10. VICKERS PROPORTIONAL CONTROL VALVE ASSEMBLY (HYDRAULIC CONTROLS)
(OCTOBER 1994 TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
