JLG 70H Parts Manual - Manual (Page 371)

3120290 5-25
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
FIGURE 5-10. STEER CYLINDER ASSEMBLIES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
STEER CYLINDER ASSEMBLIES Ref.
Cylinder Usage Chart:
1681562 2WD Front (Prior to May 1992)
1681562
2WD Front without Tow Package (May 1992 to
Present)
1682780 2WD Front with Tow Package (May 1992 to Present)
1681555 4WD Front (Prior to February 1990)
1682203 4WD Front (February 1990 to May 1992)
1681555 4WD Front (May 1992 to Present)
1681555 4WS Option Rear
STEER CYLINDER ASSEMBLY Ref.
1681562 STEER CYLINDER ASSEMBLY Ref. H
1682780 STEER CYLINDER ASSEMBLY Ref. -
1681555 STEER CYLINDER ASSEMBLY Ref. D
1682203 STEER CYLINDER ASSEMBLY Ref. B
1 Barrel Assembly Options: 1
1681433 1681562 Cylinder Assembly
1682781 1682780 Cylinder Assembly
1681413 1681555 & 1682203 Cylinder Assembly
2 Rod Assembly Options: 1
1681435 1681562 Cylinder Assembly
1682783 1682780 Cylinder Assembly
1681411 1681555 Cylinder Assembly
1682202 1682203 Cylinder Assembly
3 1120108 Retainer 1
4 Head Options: 1
1681322 1681562 & 1682780 Cylinder Assembly
1681344 1681555 & 1682203 Cylinder Assembly
5 Spacer Options: 1
4562687 1681562 Cylinder Assembly
1440142 1682780 Cylinder Assembly
4562851 1681555 Cylinder Assembly
4564637 1682203 Cylinder Assembly
6 3480134 Piston 1
7 Nut Option: 1
3300187 Nut (Prior to January 1991)
3300273 Nut, Hex (January 1991 to Present)
8 Kit Seal, Wiper 1
9 Kit Seal, Rod 1
10 Kit Ring, Wear 1
11 Kit O-Ring
12 Collar 1
Not Required 1681562, 1681555 & 1682203 Cylinder Assembly
4740377 1682780 Cylinder Assembly
13 Kit Seal, Piston 1
14 Kit Ring, Wear 1
