2-100 3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
123 1320059 Clamp 1
124 4844235 Snorkel 1
125 3311405 Locknut 1/4”-20NC 6
126 1060045 Cable, Battery (Aux Relay to Start Relay) 1
127 4751500 Flatwasher 5/16” 2
128 4740362 Washer, Fender 6
129 4761500 Lockwasher 5/16” 2
130 2420030
Gauge, Oil Pressure (Not Shown - Located at
Ground Control)
1
131 1120423 Raincap 1
132 3536008 Plate, Cover 1
133 4791600 Starwasher 3/8” 3
134 4791400 Starwasher 1/4” 2
135 Clamp Options: 1
Not Required Engine, Deutz F3L912
1320021 Engine, Deutz F4L912
136 2180536 Fitting, Barbed (July 1994 to Present) 1
0237627 ELECTRICAL PANEL ASSEMBLY Ref. F
201 3740059 Relay 1
202 3321001 Nut #10-32NF 3
203 3310801 Nut #8-32NC 1
204 3530425 Plate, Mounting 1
205 3740080 Relay, Sealed 1
206 3740067 Relay 2
207 3300220 Nut, Special 6
208 0641405 Bolt 1/4”-20NC x 5/8” 7
209 4761400 Lockwasher 1/4” 7
210 3311401 Nut 1/4”-20NC 7
211 4711400 Flatwasher 1/4” Narrow 6
4931671
ENGINE DISTRESS INSTALLATION (PRIOR TO SEP-
TEMBER 1994)
Ref. B
0255152
ENGINE DISTRESS INSTALLATION (SEPTEMBER
1994 TO PRESENT)
Ref. B
301 2180360 Fitting, Tee 1
4360065 Switch, Oil Pressure 1
4360179
Switch, Temperature (Not Shown - Located in Head
Under Shroud)
1
0251683 ENGINE RUN LIGHT INSTALLATION Ref. B
302 4360037 Switch, Pressure 1
2180360 Fitting, Tee 1
FIGURE 2-25. DEUTZ ENGINE INSTALLATION WITH NOISE REDUCTION (BUILT DECEMBER 1992
TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
