SECTION 7 ELECTRICAL
4931626
Ground Control Box Wiring Diagram (Prior to
May 1994) (See Ground Control Box
Installation for Harnesses)
Ref.
G
4932704
Ground Control Box Wiring Diagram (May
1994 to Present) (See Ground Control Box
Installation for Harnesses)
Ref.
6
Wiring Diagrams - Ford:
Ref.
—
4931629/1280764
Engine Wiring Diagram - Std (Prior to June
1987)
Ref.
B/B
4360228
Switch, Remote Speed Set
1
4920979
Harness, Engine
1
4931685/1280826
Engine Wiring Diagram-Std (June 1987 -
February 1995)
Ref.
F/H
4360228
Switch, Remote Speed Set
1
4920997
Harness, Engine (June 1987 to March 1991)
1
4921309
Harness, Engine (March 1991 to Feb 1995)
1
4932745/1282353*
Engine Wiring Diagram - Std (Feb 1995 - May
1995)
Ref.
-/B
4921716
Harness, Engine
1
4932811/1282459*
Engine Wiring Diagram - Std (May 1995 -
Present)
Ref.
B/B
4921761
Harness, Engine
1
4931687/
1281189
Engine Wiring Diagram - UL dual Fuel (Prior
to February 1995)
Ref.
A/C
4920997
Harness, Engine (June 1987 to March 1991)
1
4921309
Harness, Engine (March 1991 to Feb 1995)
1
4360228
Switch, Remote Speed Set
1
4932768
Engine Wiring Diagram - UL Dual Fuel (Feb
1995 to Present)
Ref.
A/C
3990010
Diode 6 Amp
3
4360228
Switch, Remote Speed Set
1
2400026
Fuse 5 Amp
1
4931738/1281129
Engine Wiring Diagram - UL LP Gas Only
With Battery Disconnect
Ref.
B/C
4360228
Switch, Remote Speed Set
1
2400008
Fuse 3/4 Amp
1
2400006
Fuse 5 Amp
1
3990010
Diode - 6 Amp
6
4931996/
1281189
Engine Wiring Diagram - UL LP Gas Only
With P.G. Electronics
Ref.
A/C
4360228
Switch, Remote Speed Set
1
4920997
Harness, Engine (July 1989 to March 1991)
1
4921309
Harness, Engine (March 1991 to Present)
1
1060330
Cable, Electrical - 16/3
23 Ft.
1060331
Cable, Electrical - 16/4
38 Ft.
4931620
Ground Control Wiring Diagram (Prior to May
1994) (See Ground Control Box Installation
for Harnesses)
Ref.
G
4932704
Ground Control Wiring Diagram (May 1994 to
Present) (See Ground Control box Installa-
tion for Harnesses)
Ref.
6
