4-46 3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
0250143 SELF-CLOSING GATE INSTALLATION Ref. A
9 4160028 Spring 1
0900232 Bracket (Door Mounted) 1
0901056 Bracket (Platform Mounted) 1
4220007 Stop, Door 1
10 Not Used
11 Not Used
PLATFORM BUMPERS INSTALLATION
(WELDED-ON TYPE)
Ref.
0250689
3’x5’ STANDARD PLATFORM WITH STANDARD
CONTROLS
Ref. C
0251162
3’x5’ STANDARD PLATFORM WITH HYDRAULIC
CONTROLS
Ref. C
0251035 3’x6’ STANDARD PLATFORM Ref. C
0251348 3’x8’ STANDARD PLATFORM Ref.
0251349 3’x5’ EXTEND-A-REACH PLATFORM Ref.
0251350 3’x6’ EXTEND-A-REACH PLATFORM Ref.
0250919 3’x5’ LOW MOUNT PLATFORM Ref.
0253462 3’x6’ LOW MOUNT PLATFORM Ref. A
0252902 3’x8’ LOW MOUNT PLATFORM Ref. A
12 4360305 Switch, Proximity - U/L Machines 4
4360215 Switch, Proximity - Standard Machines 4
4460521 Connector, Strain Relief 4
13 0940038 Padding, Bumper A/R
14 4360274 Switch, Push Button (Override) 1
3251596 Nameplate - Override 1
3740049 Relay (Not Shown) 1
PLATFORM BUMPERS INSTALLATION - SOFT
TOUCH SYSTEM (CHAIN MOUNTED TYPE)
Ref.
0254463 3’x5’ LOW MOUNT PLATFORM Ref. 6
0254464 3’x6’ LOW MOUNT PLATFORM Ref. 7
0254465 3’x8’ LOW MOUNT PLATFORM Ref. 7
15 0630440 Eyebolt 8
3010088 Link, Quick 8
1260136 Chain A/R
16 4360057 Switch, Limit 1
0200048 Arm, Actuator 1
17 0940038 Padding (Bottom Rail) A/R
1670663
Padding (Rail Behind Console Box) (Prior to S/N
44770)
1
1670664 Padding (LH Top Rail - 36” x 60” Platform) 1
1670715 Padding (LH Top Rail - 36” x 72” Platform) 1
1670720 Padding (LH Top Rail - 36” x 96” Platform) 1
1670665 Padding (Vertical Rails) 4
1670666 Padding (Gate) 1
1670667 Padding (RH Top Rail - 36” x 60” Platform) 1
1670716 Padding (RH Top Rail - 36” x 72” Platform) 1
FIGURE 4-10. OPTIONAL COMMON PLATFORM MOUNTED COMPONENTS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
