JLG 70H Parts Manual User Manual
Page 113
3120290
2-35
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-8. VICKERS PROPORTIONAL CONTROL VALVE ASSEMBLY (PRIOR TO OCTOBER
1994)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
4640524
VICKERS PROPORTIONAL CONTROL VALVE ASSEM-
BLY (4 SECTION) (STANDARD) (PRIOR TO OCTOBER
1994)
Ref.
-
4640561
VICKERS PROPORTIONAL CONTROL VALVE ASSEM-
BLY (4 SECTION) (HYDRAULIC CONTROLS) (PRIOR
TO OCTOBER 1994)
Ref.
-
4640514
VICKERS PROPORTIONAL CONTROL VALVE
ASSEMBLY (3 SECTION) (PRIOR TO OCTOBER 1994)
Ref.
-
1
7006747
Inlet Body (Standard)
1
Consult Factory
Inlet Body (Hydraulic Controls)
1
2
7006725
Setscrew (Standard Only)
1
3
7006733
Plug
1
4
Kit
O-Ring
5
5
Kit
O-Ring
5
6
Kit
O-Ring
5
7
7009350
Working Section - Complete (Drive) (4 Section)
(Standard)
1
7009355
Working Section - Complete (Drive) (4 Section)
(Hydraulic Controls)
1
7006760
Working Section - Complete (Drive) (3 Section)
1
8
7006762
Working Section - Complete (Lift) (Standard)
1
7009356
Working Section - Complete (Lift) (Hydraulic Controls)
1
9
7009351
Working Section - Complete (Telescope) (4 Section
Only) (Standard)
1
7009357
Working Section - Complete (Telescope) (4 Section
Only) (Hydraulic Controls)
1
10
7006763
Working Section - Complete (Swing) (Standard)
1
7009358
Working Section - Complete (Swing) (Hydraulic
Controls)
1
11
7012325
Nut, Retaining
2
12
Kit
O-Ring
2
13
7009316
Core Tube (Includes O-Ring)
2
14
7009315
Coil and Frame
2
15
7009319
Pin
2
16
Kit
O-Ring
2
17
7006744
Spool
2
18
7006726
Plug, Torque
2
19
Kit
O-Ring
2
20
7006728
Shim Kit
2
21
7006729
Spring
2
22
7006730
Poppet
2
23
7006731
Ball
2
24
7006745
Screw
8
25
Cap, End (Not Sold Separately)
2
26
7006746
Ball
2
27
Kit
O-Ring
2
28
7009323
Plug
2
29
Kit
Gasket
2
30
7009324
Spring
2
