SECTION 1 FRAME
24 (cont’d) 3323002
4WD Oscillating Axle Machines Built Prior to May
1992
25 Nut, 1”-8NC Options: 1
Not Required Machines with Oscillating Axle
3312601 Machines with Fixed Axle
26 Locknut 1”-8NC Options: 1
Not Required Machines with Oscillating Axle
3312605 Machines with Fixed Axle
0253189
STEERING COMPONENTS INSTALLATIONS - 60H
2WD MACHINES BUILT MAY 1992 TO PRESENT
Ref. C
0253190
STEERING COMPONENTS INSTALLATION - 70H
2WD MACHINES BUILT MAY 1992 TO PRESENT
Ref. C
0253177
STEERING COMPONENTS INSTALLATION - 4WD
MACHINES BUILT MAY 1992 TO PRESENT
Ref. C
51
Steer Cylinder Assembly Options (See Section 5 for
Breakdown):
1
1682780 2WD
1681555 4WD
52 Tie-Rod Options: 1
3841149 2WD
3841142 4WD
53 3422106 Pin 2
54 Bolt Options: 1
0641610 Bolt 3/8”-16NC x 1 1/4” (2WD)
0641608 Bolt 3/8”-16NC x 1” (4WD)
55 4751600 Flatwasher 3/8” 1
56 4761600 Lockwasher 3/8” 1
57 Locknut 1”-8NC Options: 1
3300243 2WD
Not Required 4WD
58 4712600 Flatwasher 1” Narrow 1
59 4740155 Washer, Thrust 3
60 3760143 Ring, Retaining 1
61 Pin Options: 1
3422117 2WD
3422119 4WD
62 3420372 Hairpin 1
63 Hitch Options: 1
4844215 2WD
4844230 4WD
64 Decal - Caution Options: 1
1701781 2WD - Decal (Prior to May 1994)
1702307 2WD - Decal (May 1994 to Present)
1701782 4WD - Decal (Prior to May 1994)
1702307 4WD - Decal (May 1994 to Present)
65- 72 Not Shown
Note: Use Standard Parts when required 2WD
Machines.
A/R
65 3431622 Pin, Clevis (4WD Machines Only) 1
FIGURE 1-20. TOW PACKAGE INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
