JLG 70H Parts Manual - Manual (Page 45)

3120290 1-37
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
FIGURE 1-9. DRIVE MOTOR ASSEMBLY - REXROTH
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160204 DRIVE MOTOR ASSEMBLY - REXROTH Ref. A
Note: Used with Vickers Valves built May 1992 to
Present)
1 7012701 Shaft - 13 Teeth 1
2 Kit Seal, Shaft 1
3 7012702 Bearing, Cradle 2
4 Not Available Housing 1
5 7012703 Rod, Piston 1
6 7012704 Piston, Stroking 1
7 Kit O-Ring 1
8 7012705 Nut, Adaptor 1
9 7012706 Bearing, Roller 1
10 7012707 Bolt, Metric Socket Head M12 x 65 4
11 7012708 Block, Port 1
12 7012709 Shim 1
13 7012710 Pin, Dowel M6 x 18 1
14 Kit O-Ring 1
15 7012711 Nut, Cap M10 x 1 1
16 7012712 Screw, Adjusting 1
17 Kit O-Ring 1
18 7012713 Nut, Jam M10 x 1 1
19 Kit Rotary Group Assembly 1
20 Not Available Plug 1
21 Kit Plate, Swash 1
22 7012714 Bearing, Roller 1
23 7012715 V-Ring 1
24 7012700 Control Plate Assembly 1
— — — — — — — — — —
2900788
Seal Kit (Includes Items 2, 7, 14, 17 and O-Rings under
Item 24)
1
7012716 Rotary Group Kit (Includes Items 19 and 21) 1
