SECTION 1 FRAME
FIGURE 1-14. BRAKE ASSEMBLY - MICO
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0920084 Prior to S/N 33476 Ref. A
0920110 S/N 33476 to S/N 51532 Ref. B
0920117 S/N 51532 to S/N 57512 (Replace complete unit with
p/n 0920119) Ref. B
0920119 S/N 57512 to Present Ref. A
Note: Used on 60H 2WD & 4WD & 70H 2WD & 4WD. Ref.
1 Shaft Options: 1
7011712 0920084 Brake (Prior to S/N 33476)
7011712 0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
2 Guide, Spring Options: 1
7011717 0920084 Brake (Prior to S/N 33476)
7018606 0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
3 Spring Options: A/R
7007979 0920084 Brake (Inner) (Prior to S/N 33476) 6
7007980 0920084 Brake (Outer) (Prior to S/N 33476) 6
7007970 0920110 Brake (Red) (S/N 33476 to S/N 51532) 6
7018602 0920110 Brake (Blue) (S/N 33476 to S/N 51532) 3
Kit 0920119 Brake (Red) (S/N 57512 to Present) 4
Kit 0920119 Brake (Blue) (S/N 57512 to Present) 2
4 Housing Options: 1
7011713 0920084 Brake (Prior to S/N 33476)
7018605 0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
5 Return Plate & Separator Assembly Options: A/R
Kit Return, Plate - 0920084 Brake (Prior to S/N
33476) 1
7011715 Separator Assy - 0920084 Brake (Prior to S/N
33476) 2
7011714 Pin 4
7007983 Separator 2
Kit Return Plate & Separator - 0920110 Brake (S/N
33476 to S/N 51532) 1
Kit Return Plate & Separator - 0920119 Brake (S/N
57512 to Present)
6 Kit Rotor 2
7 Kit Stator 2
8 Kit Seal, Case 1
9 Bolt, Washer Head Options: 4
7007985 0920084 Brake (Prior to S/N 33476)
7018607 0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
10 Cover Options: 1
7007986 0920084 Brake (Prior to S/N 33476)
7007986 0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
