FIGURE 4-7. CONSOLE BOX ASSEMBLY - OEM CONTROLLERS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLY - OEM CONTROLLERS Ref.
0238264
CONSOLE BOX ASSEMBLY - 2WD MACHINES
WITHOUT CAPACITY INDICATOR AND WITHOUT
PROP TELE
Ref. 7
0238179
CONSOLE BOX ASSEMBLY - 2WD MACHINES WITH
CAPACITY INDICATOR AND WITHOUT PROP TELE
AND WITH STANDARD PLATFORM
Ref. 11
0254737
CONSOLE BOX ASSEMBLY - 2WD MACHINES WITH
CAPACITY INDICATOR AND WITHOUT PROP TELE
AND WITH LOW MOUNT PLATFORM
Ref. 2
0238263
CONSOLE BOX ASSEMBLY - 2WD MACHINES
WITHOUT CAPACITY INDICATOR AND WITH PROP
TELE
Ref. 7
0238180
CONSOLE BOX ASSEMBLY - 2WD MACHINES WITH
CAPACITY INDICATOR AND WITH PROP TELE
Ref. 8
0238290
CONSOLE BOX ASSEMBLY - 4WD MACHINES WITH
CAPACITY INDICATOR AND WITHOUT PROP TELE
Ref. 7
0251918
CONSOLE BOX ASSEMBLY - 4WD MACHINES
WITHOUT CAPACITY INDICATOR AND WITH PROP
TELE
Ref. 3
0238289
CONSOLE BOX ASSEMBLY - 4WD MACHINES WITH
CAPACITY INDICATOR AND WITH PROP TELE
Ref. 7
1 0860538 Box Weldment 1
2600132 Hinge (Top to Bottom) 1
2600105 Hinge (Rear Access Door) 1
2940052 Latch 2
2 3251678 Lid 1
3 4420038 Tape, Insulation 45 in/
38cm
4 0100001 Adhesive (Not Shown) A/R
5 0100009 Silicone, RTV (Not Shown) A/R
6 3960251 Gasket 1
7 Decal - Capacity Options: 1
3251551
Decal - Capacity (Machines Without Capacity Indi-
cator)
2960006
Lens, Capacity Indicator (Machines With Capacity
Indicator)
8 3911014 Screw, Round Head #10-24NC x 7/8” 4
9 4771000 Starwasher #10 4
10 3311001 Nut #10-24NC 6
11 Controller, OEM Options: 2
1600092 Prior to S/N 27148
1600247
S/N 27148 to Present
12 Not Used
13 4360202 Switch, Toggle - DPDT/MC/CO 3
14 4060087 Shield, Switch A/R
15 3790012 O-Ring A/R
16 4360199 Switch, Toggle - SPST 5
17 2920015 Lamp 1
