3120290
5-17
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
FIGURE 5-6. PLATFORM LEVEL CYLINDER ASSEMBLIES (MODEL 60H AND 70H BUILT
DECEMBER 1986 TO APRIL 1992)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
PLATFORM LEVEL CYLINDER ASSEMBLIES (MODEL
60H AND 70H BUILT DECEMBER 1986 TO APRIL
1992)
Ref.
1681722
PLATFORM LEVEL CYLINDER ASSEMBLY
Ref.
D
1
1681331
Rod Assembly
1
0960097
Bushing, Bronze
1
2
1681721
Barrel Assembly
1
3
1680892
Head
1
4
1120179
Retainer
1
5
1440142
Spacer
1
6
3480120
Piston
1
7
Nut Options:
1
3300101
Nut (Prior to January 1991)
3300272
Nut, hex (January 1991 to April 1992)
8
4640509
Valve, Cartridge
2
2900792
Seal Kit - 4640509 Valve
2
9
Kit
Seal, Wiper
1
10
Kit
Seal, Rod
1
11
Kit
Ring, Wear
1
12
Kit
O-Ring
1
13
Kit
Ring, Back-up
2
14
Kit
Ring, Wear
1
15
Kit
Seal, Piston
1
16
Kit
O-Ring
1
17
0100011
Loctite #242
A/R
18
2200201
Plug 1/8”
2
19
2200202
Plug 1/4”
2
20
0100020
Sealant, Thread
A/R
21
0100038
Primer, Locking
A/R
22
Not Used
23
3900170
Setscrew 3/8”-16NC x 3/8”
1
24
0100035
Locking Compound
A/R
25
2160001
Fitting, Grease - 90º
1
26
2160002
Fitting, Grease
1
— — — — — — — — — —
2900381
Seal Kit - 1681722 Cylinder (Includes Items 9-16)
1
