SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-25. DEUTZ ENGINE INSTALLATION WITH NOISE REDUCTION (BUILT DECEMBER 1992
TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
DEUTZ ENGINE INSTALLATION WITH NOISE
REDUCTION (BUILT DECEMBER 1992 TO PRESENT)
Ref.
0253385 DEUTZ F3L912 ENGINE ASSEMBLY - STANDARD Ref. D
0253387 DEUTZ F3L912 ENGINE ASSEMBLY - CLEAN BURN Ref. C
0253327 DEUTZ F4L912 ENGINE ASSEMBLY - STANDARD Ref. C
0254243 EXHAUST INSTALLATION Ref. A
1 Engine Options: 1
2000066 Engine, Deutz F3L912 - Standard
2000094 Engine, Deutz F3L912W - Clean Burn
2000083 Engine, Deutz F4L912 - Standard
2 3600139 Pump Assembly (See Figure 2-39 for Breakdown) 1
3 3200229 Support, Motor (Front) 1
4 3200228 Support, Motor (Rear) 2
5 3200133 Mount, Motor (Front) 1
6 3200183 Mount, Motor (Rear) 2
7 3200227 Plate, Mounting (Front) 1
8 3200306 Plate, Mounting (Rear) 1
9 4640742 Valve, Drain 1
10 Hardware Options: A/R
4565945 Tube (Engine, Deutz F3L912) 1
2720042 Hose (Engine, Deutz F4L912) 6 in.
11 4832000 Lockwasher, Metric 10mm 2
12 Cable, Battery (Engine to Ground) Options: 1
1060045 Engine, Deutz F3L912
1060044 Engine, Deutz F4L912
13 0641810 Bolt 1/2”-13NC x 1 1/4” 2
14 4761800 Lockwasher 1/2” 2
15 Not Used
16 0642032 Bolt 5/8”-11NC x 4” 3
17 3312005 Locknut 5/8”-11NC 3
18 4740242 Flatwasher, Special 3
19 0701427 Bolt, Metric 14mm x 100mm 4
20 4740191 Lockwasher, Metric 14mm 4
21 0701215 Bolt, Metric 12mm x 35mm A/R
22 4832100 Lockwasher 12mm 8
23 3220082 Muffler 1
24 0340041 Band, Muffler 1
25 0901849 Bracket, Muffler 1
26 0701015 Bolt, Metric 10mm x 35mm 2
27 4761400 Lockwasher 1/4” 3
28 Locknut 1/4”-20NC Options: A/R
3311405 Prior to July 1994 2
3311401 July 1994 to Present 2
29 0641508 Bolt 5/16”-18NC x 1” 2
30 2220001 Fitting, Swivel (Prior to July 1994) 1
31 4420001 Tape, Sealing A/R
