3120290 2-183
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-43. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH VICKERS
PROPORTIONAL VALVES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: See Section 10 for U/L Approved Ground
Control Box
0237855
GROUND CONTROL BOX ASSEMBLY - MACHINES
WITH STANDARD CAPACITY BUILT PRIOR TO MAY
1994
Ref. G
0860908
GROUND CONTROL BOX ASSEMBLY - MACHINES
WITH STANDARD CAPACITY BUILT MAY 1994 TO
PRESENT
Ref. 4
0251659
GROUND CONTROL BOX ASSEMBLY - MACHINES
WITH 750 LBS. CAPACITY BUILT PRIOR TO MAY
1994
Ref. -
0860924
GROUND CONTROL BOX ASSEMBLY - MACHINES
WITH 750 LBS. CAPACITY BUILT MAY 1994 TO
PRESENT
Ref. A
1 0860547 Box 1
2 Lid Options: 1
3251650
Machines with Standard Capacity (Built Prior to
May 1994)
3252343
Machines with Standard Capacity (Built May 1994
to S/N 48804)
3252638
Machines with Standard Capacity (S/N 48804 to
Present)
3252088
Machines with 750 Lbs. Capacity (Built Prior to
May 1994)
3252344
Machines with 750 Lbs. Capacity (Built May 1994
to Present)
3 2600093 Hinge 1
4 3911006 Screw, Round Head #10-24NC x 3/8” 4
5 4761000 Lockwasher #10 20
6 3311001 Nut #10-24NC 19
7 3911008 Screw, Round Head #10-24NC x 1/2” 12
8 3740049 Relay - SPDT 12
9 4751000 Flatwasher #10 3
10 3740016 Relay - 3PDT 2
11 4120002 Socket, Relay 2
12 3910606 Screw, Round Head #6-32NC x 3/8” 2
13 3910610 Screw. Round Head #6-32MC x 5/8” 3
14 4760600 Lockwasher #6 5
15 3310601 Nut #6-32NC 5
16 0750806 Screw #8 x 3/4” 2
17 3300177 Nut, Tinnerman 2
18 4420037 Strip, Rubber 33 in.
19 0100001 Adhesive (Not Shown) A/R
20 4460051 Connector, Strain Relief 3
21 3300048 Nut, Conduit 4
22 0960238 Bushing 4
23 4360186 Breaker, Circuit - 35Amp 1
24 Not Used
